Spacewalk DB Schema - Table-RHNACTIONKICKSTART

Main Tables Views Materialized Views Indexes Constraints Triggers Procedures Functions Packages Sequences Java Sources Sanity Check Index DDL scrips

Description Columns Primary key Check Constraints Foreign keys Unique Keys Options Indexes Referenced by Triggers Partitions

RHNACTIONKICKSTART

DDL script

Columns

Name	Type	Nullable	Default value
ID	NUMBER(38)	N
ACTION_ID	NUMBER(38)	N
APPEND_STRING	VARCHAR2(1024)	Y
KSTREE_ID	NUMBER(38)	N
STATIC_DEVICE	VARCHAR2(32)	Y
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)

Primary key:

Constraint Name	Columns
RHN_ACTIONKS_ID_PK	ID

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_ACTIONKS_AID_FK	ACTION_ID	RHNACTION	RHN_ACTION_PK	CASCADE
RHN_ACTIONKS_KSTID_FK	KSTREE_ID	RHNKICKSTARTABLETREE	RHN_KSTREE_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_ACTIONKS_AID_UQ	NORMAL	UNIQUE	ACTION_ID	DDL script
RHN_ACTIONKS_ID_IDX	NORMAL	NONUNIQUE	ID	DDL script

Referenced by:

Table	Constraint
RHNACTIONKICKSTARTFILELIST	RHN_ACTIONKSFL_ASKID_FK

Triggers

RHN_ACTIONKS_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_actionks_mod_trig
before insert or update on rhnActionKickstart
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := sysdate;
end;
