RHNCHANNELFAMILYMEMBERS

DDL script

Columns

Name	Type	Nullable	Default value
CHANNEL_ID	NUMBER(38)	N
CHANNEL_FAMILY_ID	NUMBER(38)	N
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_CF_FAMILY_FK	CHANNEL_FAMILY_ID	RHNCHANNELFAMILY	RHN_CHANNEL_FAMILY_ID_PK	NO ACTION
RHN_CF_MEMBERS_C_FK	CHANNEL_ID	RHNCHANNEL	RHN_CHANNEL_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_CF_C_UQ	NORMAL	UNIQUE	CHANNEL_ID	DDL script
RHN_CF_MEMBER_CF_C_IDX	NORMAL	NONUNIQUE	CHANNEL_FAMILY_ID , CHANNEL_ID	DDL script
RHN_CF_MEMBER_UQ	NORMAL	UNIQUE	CHANNEL_ID , CHANNEL_FAMILY_ID	DDL script

Triggers

RHN_CF_MEMBER_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_cf_member_mod_trig
before insert or update on rhnChannelFamilyMembers
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := sysdate;
end;
