RHNEMAILADDRESS

DDL script

Columns

Name	Type	Nullable	Default value
ID	NUMBER(38)	N
ADDRESS	VARCHAR2(128)	N
USER_ID	NUMBER(38)	N
STATE_ID	NUMBER(38)	N
NEXT_ACTION	DATE	Y
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)

Primary key:

Constraint Name	Columns
RHN_EADDRESS_ID_PK	ID

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_EADDRESS_SID_FK	STATE_ID	RHNEMAILADDRESSSTATE	RHN_EASTATE_ID_PK	NO ACTION
RHN_EADDRESS_UID_FK	USER_ID	WEB_CONTACT	WEB_CONTACT_PK	CASCADE

Unique Keys:

Constraint name	Columns
RHN_EADDRESS_UID_SID_UQ	USER_ID , STATE_ID

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_EADDRESS_ID_IDX	NORMAL	NONUNIQUE	ID	DDL script
RHN_EADDRESS_NIUSA_IDX	NORMAL	NONUNIQUE	NEXT_ACTION , ID , USER_ID , STATE_ID , ADDRESS	DDL script
RHN_EADDRESS_UID_SID_ADDR_IDX	NORMAL	NONUNIQUE	USER_ID , STATE_ID , ADDRESS	DDL script

Triggers

RHN_EADDRESS_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_eaddress_mod_trig
before insert or update on rhnEmailAddress
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := sysdate;
end;
