RHNSATELLITESERVERGROUP

DDL script

Columns

Name	Type	Nullable	Default value
SERVER_ID	NUMBER(38)	N
SERVER_GROUP_TYPE	NUMBER(38)	N
MAX_MEMBERS	NUMBER(38)	Y
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SATSG_SGTYPE_FK	SERVER_GROUP_TYPE	RHNSERVERGROUPTYPE	RHN_SERVERGROUPTYPE_ID_PK	NO ACTION
RHN_SATSG_SID_FK	SERVER_ID	RHNSATELLITEINFO	RHN_SATELLITE_INFO_SID_UQ	CASCADE

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_SATSG_SID_SGT_UQ	NORMAL	UNIQUE	SERVER_ID , SERVER_GROUP_TYPE	DDL script

Triggers

RHN_SATSG_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_satsg_mod_trig
before insert or update on rhnSatelliteServerGroup
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := sysdate;
end;
