RHNSERVERGROUPNOTES

DDL script

Columns

Name	Type	Nullable	Default value
ID	NUMBER(38)	N
CREATOR	NUMBER(38)	Y
SERVER_GROUP_ID	NUMBER(38)	N
SUBJECT	VARCHAR2(80)	N
NOTE	VARCHAR2(4000)	N
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)

Primary key:

Constraint Name	Columns
RHN_SERVERGRP_NOTE_ID_PK	ID

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_SERVERGRP_NOTE_CREATOR_FK	CREATOR	WEB_CONTACT	WEB_CONTACT_PK	SET NULL
RHN_SERVERGRP_NOTE_FK	SERVER_GROUP_ID	RHNSERVERGROUP	RHN_SERVERGROUP_ID_PK	CASCADE

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_SERVERGRP_NOTE_CREATOR_IDX	NORMAL	NONUNIQUE	CREATOR	DDL script
RHN_SERVERGRP_NOTE_ID_PK	NORMAL	UNIQUE	ID	DDL script
RHN_SERVERGRP_NOTE_SRVR_ID_IDX	NORMAL	NONUNIQUE	SERVER_GROUP_ID	DDL script

Triggers

RHN_SERVERGROUP_NOTE_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_servergroup_note_mod_trig
BEFORE INSERT OR UPDATE ON rhnServerGroupNotes
FOR EACH ROW

REFERENCING NEW AS NEW OLD AS OLD
BEGIN
        :new.modified := sysdate;
END;
