RHNUSERINFO

DDL script

Columns

Name	Type	Nullable	Default value
USER_ID	NUMBER(38)	N
NO_CLEAR_SETS	NUMBER(38)	N	(0)
PAGE_SIZE	NUMBER(38)	N	(20)
EMAIL_NOTIFY	NUMBER(38)	N	(1)
BAD_EMAIL	NUMBER(38)	N	(0)
TZ_OFFSET	NUMBER(38)	N	(-5)
TIMEZONE_ID	NUMBER(38)	Y
SHOW_APPLIED_ERRATA	CHAR(1)	N	('N')
SHOW_SYSTEM_GROUP_LIST	CHAR(1)	N	('N')
AGREED_TO_TERMS	CHAR(1)	N	('N')
USE_PAM_AUTHENTICATION	CHAR(1)	N	('N')
LAST_LOGGED_IN	DATE	Y
AGREED_TO_WS_TERMS	CHAR(1)	Y
AGREED_TO_ES_TERMS	CHAR(1)	Y
CREATED	DATE	N	(sysdate)
MODIFIED	DATE	N	(sysdate)
PREFERRED_LOCALE	VARCHAR2(8)	Y

Check Constraints:

Constraint Name	Check Condition
RHN_USER_INFO_AGREED_CK	agreed_to_terms in ('Y','N')
RHN_USER_INFO_ES_CK	agreed_to_es_terms is null or agreed_to_es_terms in ('Y','N')
RHN_USER_INFO_PAM_CK	use_pam_authentication in ('Y','N')
RHN_USER_INFO_SEA_CK	show_applied_errata in ('Y','N')
RHN_USER_INFO_SSGL_CK	show_system_group_list in ('Y','N')
RHN_USER_INFO_TZOFFSET_CK	tz_offset >= -11 and tz_offset <= 13
RHN_USER_INFO_WS_CK	agreed_to_ws_terms is null or agreed_to_ws_terms in ('Y','N')

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_USER_INFO_TZID_FK	TIMEZONE_ID	RHNTIMEZONE	RHN_TIMEZONE_ID_PK	CASCADE
RHN_USER_INFO_USER_FK	USER_ID	WEB_CONTACT	WEB_CONTACT_PK	CASCADE

Unique Keys:

Constraint name	Columns
RHN_USER_INFO_UID_UQ	USER_ID

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_USER_INFO_UID_EMAIL_IDX	NORMAL	NONUNIQUE	USER_ID , EMAIL_NOTIFY	DDL script

Triggers

RHN_USER_INFO_MOD_TRIG

Legend: comment string keyword reserved word operator

CREATE TRIGGER
rhn_user_info_mod_trig
before insert or update on rhnUserInfo
for each row

REFERENCING NEW AS NEW OLD AS OLD
begin
	:new.modified := sysdate;
end rhn_user_info_mod_trig;
