RHN_REDIRECTS

Description:

rdrct redirect definitions

Columns

Name	Type	Nullable	Default value	Comment
RECID	NUMBER(12)	N
CUSTOMER_ID	NUMBER(12)	Y
CONTACT_ID	NUMBER(12)	Y
REDIRECT_TYPE	VARCHAR2(20)	N
DESCRIPTION	VARCHAR2(25)	Y
REASON	VARCHAR2(2000)	Y
EXPIRATION	DATE	N
LAST_UPDATE_USER	VARCHAR2(40)	Y
LAST_UPDATE_DATE	DATE	Y
START_DATE	DATE	N
RECURRING	NUMBER(12)	N	0
RECURRING_FREQUENCY	NUMBER(12)	Y	2
RECURRING_DURATION	NUMBER(12)	Y	0
RECURRING_DUR_TYPE	NUMBER(12)	Y	12

Primary key:

Constraint Name	Columns
RHN_RDRCT_RECID_PK	RECID

Check Constraints:

Constraint Name	Check Condition
RHN_RDRCT_RECUR_FREQ_VALID	recurring_frequency in (2,3,6)
RHN_RDRCT_RECUR_VALID	recurring in (0, 1)
RHN_RDRCT_REC_DTYPE_VALID	recurring_dur_type in (12,11,5,3,1)
RHN_RDRCT_START_LTE_EXPIR	start_date <= expiration

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_RDRCT_CNTCT_CONTACT_ID_FK	CONTACT_ID	WEB_CONTACT	WEB_CONTACT_PK	NO ACTION
RHN_RDRCT_CSTMR_CUSTOMER_ID_FK	CUSTOMER_ID	WEB_CUSTOMER	WEB_CUSTOMER_ID_PK	NO ACTION
RHN_RDRCT_RDRTP_REDIR_TYPE_FK	REDIRECT_TYPE	RHN_REDIRECT_TYPES	RHN_RDRTP_NAME_PK	NO ACTION

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_RDRCT_CID_IDX	NORMAL	NONUNIQUE	CONTACT_ID	DDL script
RHN_RDRCT_CUSTOMER_ID_IDX	NORMAL	NONUNIQUE	CUSTOMER_ID	DDL script
RHN_RDRCT_RECID_PK	NORMAL	UNIQUE	RECID	DDL script
RHN_RDRCT_REDIRECT_TYPE_IDX	NORMAL	NONUNIQUE	REDIRECT_TYPE	DDL script

Referenced by:

Table	Constraint
RHN_REDIRECT_CRITERIA	RHN_RDRCR_RDRCT_REDIRECT_ID_FK
RHN_REDIRECT_EMAIL_TARGETS	RHN_RDRET_RDRCT_REDIRECT_ID_FK
RHN_REDIRECT_GROUP_TARGETS	RHN_RDRGT_RDRCT_REDIRECT_ID_FK
RHN_REDIRECT_METHOD_TARGETS	RHN_RDRMT_RDRCT_REDIRECT_ID_FK
