RHN_CHECK_PROBE

Description:

CHKPB Service check probe definitions (monitoring)

Columns

Name	Type	Nullable	Default value	Comment
PROBE_ID	NUMBER(12)	N
PROBE_TYPE	VARCHAR2(12)	N	'check'
HOST_ID	NUMBER(12)	N
SAT_CLUSTER_ID	NUMBER(12)	N

Primary key:

Constraint Name	Columns
RHN_CHKPB_PROBE_ID_PK	PROBE_ID

Check Constraints:

Constraint Name	Check Condition
CHKPB_PROBE_TYPE_CK	probe_type='check'

Foreign Keys:

Constraint Name	Columns	Referenced table	Referenced Constraint	On Delete Rule
RHN_CHKPB_HOST_ID_FK	HOST_ID	RHNSERVER	RHN_SERVER_ID_PK	NO ACTION
RHN_CHKPB_RECID_PROBE_TYP_FK	PROBE_ID , PROBE_TYPE	RHN_PROBE	RHN_PROBE_RECID_PROBE_TYPE_UQ	CASCADE
RHN_CHKPB_SATCL_SAT_CL_ID_FK	SAT_CLUSTER_ID	RHN_SAT_CLUSTER	RHN_SATCL_RECID_PK	CASCADE

Options:

Option	Settings
Tablespace	DATA_TBS
Index Organized	No
Generated by Oracle	No
Clustered	No
Nested	No
Temporary	No

Indexes:

Index Name	Type	Unuqueness	Columns	DDL script
RHN_CHKPB_HOST_ID_IDX	NORMAL	NONUNIQUE	HOST_ID	DDL script
RHN_CHKPB_PID_PTYPE_UQ_IDX	NORMAL	UNIQUE	PROBE_ID , PROBE_TYPE	DDL script
RHN_CHKPB_PROBE_ID_PK	NORMAL	UNIQUE	PROBE_ID	DDL script
RHN_CHKPB_SAT_CLUSTER_ID_IDX	NORMAL	NONUNIQUE	SAT_CLUSTER_ID	DDL script
